FF14-04N Dimensions

1/2″ NPT ISO 7241-B Brass Quick Disconnect Hydraulic Male Coupler

Graphic showing how to measure body size of FF12-08N

Graphic showing how to measure thread size of FF12-08N

1/4

FF14-04N Dimensions

1/2″ NPT ISO 7241-B Brass Quick Disconnect Hydraulic Male Coupler

Graphic showing how to measure body size of FF12-08N

Graphic showing how to measure thread size of FF12-08N

1/4″ Flat Face Hydraulic Quick Connect Coupler Set, 1/4″ NPT Thread

$34.95

Free Shipping

1/4″ Flat Face Hydraulic Quick Connect Coupler Set, 1/4″ NPT Thread

In stock

SKU: FF14-04N-SET Categories: 1/4" Body, Coupler Set, Flat Face ISO 16028 Quick Couplers Tags: 1/4" Body, 1/4" NPT, Flat Face Coupler

SKU: FF14-04N-SET

Size: 1/4″ Body with 1/4″ NPT Thread

Features:

Heavy Duty Design with 7350 PSI Rating
Max Flow Rate: 6.34 GPM
Locking sleeve helps prevent accidental disconnects
Compact profile with high flow performance
Harden steel construction with anti-corrosive plating
Sleeves are hardened to resist deformation and maximize life of the coupler
Valve design that allows for a minimal pressure drops and one hand operation
Seals are rated for operating temperatures up to 250°F

Interchangeable with:

Manufacturer	Male	Female
SUMMIT	FF14M-04N	FF14F-04N
Parker FE Series	FEM-252-4FP	FEM-251-4FP
Safeway FFE49 Series	FFE491-2	FFE495-2
Faster FFH Series	FFH04 14NPT M	FFH04 14NPT F
Eaton Aeroquip FD89	FD89-1002-04-04	FD89-1001-04-04
Snap Tite 74 Series	74N4-4F	74C4-4F
Stucchi FIRG Series	800801001	800801000
Dixon HT Series	HT2F2	2HTF2
DNP PLT4 Series	FF-HPG-04-04N-NPT	FF-HPG-04-04C-NPT
Tomco FE Series	EP2-16	EC2-16

Weight	1 lbs
Dimensions	5 × 4 × 3 in
ISO Standard	16028
Style	Flat Face
Body Size	1/4"
Thread Type	NPT
Thread Size	1/4"
Coupling	Set
Body Material	Hardened Steel
Locking Type	Ball
